MSI B650M GAMING WIFI AMD AM5 mATX Gaming Motherboard

<p>B650M GAMING WIFI is designed with tonnes of connectivity, flexible tools, and a convenient Wi-Fi solution with a DDR5 memory version for gamers who want it all.</p>
<p>This is a huge step in DDR performance enhancement with the latest DDR5 memory. With a dedicated SMT welding process and MSI Memory Boost technology, B650M GAMING WIFI is ready to deliver world-class memory performance. The advanced SMT (Surface Mount Technology) welding process reduces the defect rate of slot solder joints, electromagnetism, and interference. With exclusive Memory Boost technology, MSI motherboards deliver a clean and pure high-frequency DDR5 signal.</p>
<p>Core Boost technology utilises MSI’s premium layout and optimised power design to deliver CPU current with increased speed and precision. The software supports multi-core CPUs and optimises CPU overclocking. MSI B650M GAMING WIFI series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Start games faster, load levels faster, and have a real advantage over your enemies. MSI B650M GAMING WIFI series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Start games faster, load levels faster and have a real advantage over your enemies</p>
<h3>FEATURES:</h3>
<ul>
<li>Supports AMD RyzenTM 8000 and 7000 Series Desktop Processors</li>
<li>Supports DDR5 Memory, up to 7800+ (OC) MHz</li>
<li>Core Boost : With premium layout and digital power design to support more cores and provide better performance</li>
<li>Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility</li>
<li>Lightning Fast Game experience: PCIe 4.0 slot, Lightning Gen4 M.2</li>
<li>Steel Armour: Protecting VGA cards against bending and EMI for better performance, stability and strength</li>
<li>AUDIO Boom: Reward your ears with studio-grade sound quality for the most immersive gaming experience</li>
<li>High-Quality PCB: 6-layer PCB made by 2 oz. thickened copper</li>
</ul>
<h3>SPECIFICATIONS:</h3>
<ul>
<li>Socket: AM5</li>
<li>CPU Support: Supports AMD RyzenTM 8000/7000 Series Desktop Processors</li>
<li>Chipset: AMD B650</li>
<li>DDR5 Memory: DDR5 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz</li>
<li>Max. overclocking frequency: 1DPC 1R Max speed up to 7800+ MHz; 1DPC 2R Max speed up to 6400+ MHz</li>
<li>Memory Channel: Dual-Channel DDR5</li>
<li>DIMM Slots: 2</li>
<li>Max Memory (GB): 128GB</li>
<li>PCI-E x16: 1</li>
<li>PCI-E x1: 2</li>
<li>SATA 6G: 4</li>
<li>M.2 Slot: 2</li>
<li>RAID: 0/1/10</li>
<li>LAN: Realtek® 8125BG 2.5G LAN</li>
<li>TPM pin header (Support TPM 2.0): 1</li>
<li>USB 2.0 (Rear): 2</li>
<li>USB 2.0 (Front): 4</li>
<li>USB 5Gbps Type A (Rear): 3</li>
<li>USB 5Gbps Type C (Rear): 1</li>
<li>USB 5Gbps Type A (Front): 4</li>
<li>Audio ports (Rear): 7.1-Channel High Definition Audio, Realtek^® RTL8125BG 2.5Gbps LAN</li>
<li>Wifi: AMD Wi-Fi 6E</li>
<li>Bluetooth: 5.3</li>
<li>HDMI: 1</li>
<li>DisplayPort: 1</li>
<li>DirectX: 12</li>
<li>Form Factor: mATX</li>
<li>Operating System: Support for Windows® 11 64-bit and Windows® 10 64-bit</li>
</ul>
<h3>WHAT’S IN THE BOX?</h3>
<ul>
<li>MSI B650M Gaming Wifi AMD AM5 mATX Gaming Motherboard, Black x1</li>
<li>I/O Shield x1</li>
<li>SATA Cable x1</li>
<li>EZ M.2 Clips x1</li>
<li>Wifi Antenna x1</li>
<li>Quick Install Guide x1</li>
</ul>
